Thermal Regulating & Monitoring

• Dual Fixed Thermostat
• Normally Closed (NC) Switch On: 41 F / 5 C - Switch Off: 59 F / 15 C
  Normally Open (NO) Switch On: 122 F / 50 C - Switch Off: 104 F / 40 C

• Dual Fixed Thermostat
• Normally Closed (NC) Switch On: 41 F / 5 C - Switch Off: 59 F / 15 C
  Normally Open (NO) Switch On: 95 F / 35 C - Switch Off: 77 F / 25 C

• Dual Fixed Thermostat
• Normally Closed (NC) Switch On: 59 F / 15 C - Switch Off: 77 F / 25 C
  Normally Open (NO) Switch On: 122 F / 50 C - Switch Off: 104 F / 40 C

• Dual Fixed Thermostat
• Normally Closed (NC) Switch On: 59 F / 15 C - Switch Off: 77 F / 25 C
  Normally Open (NO) Switch On: 140 F / 60 C - Switch Off: 122 F / 50 C

The FLZ series of twin thermostats integrates two independently switchable thermostats. They are available with N.C./N.O., N.C./N.C., and N.O./N.O. contacts.

• Dual Adjustable Thermostat
• Setting Range (NO): 0-60 C
  Setting Range (NO): 0-60 C

The FLZ series of twin thermostats integrates two independently switchable thermostats. They are available with N.C./N.O., N.C./N.C., and N.O./N.O. contacts.

• Dual Adjustable Thermostat
• Setting Range (NO): 32-140 F
  Setting Range (NO): 32-140 F

The ZR 011 houses two separate thermostats, allowing the independent control of heating and cooling or other equipment.

• Dual AdjustableThermostat
• Setting Range (NO): 0-60 C
  Setting Range (NO): 0-60 C

• Dual Fixed Thermostat
• Normally Open (NO) Switch On: 122 F / 40 C - Switch Off: 104 F / 50 C
  Normally Open (NO) Switch On: 140 F / 60 C - Switch Off: 122 F / 50 C

The ZR 011 houses two separate thermostats, allowing the independent control of heating and cooling or other equipment.

• Dual AdjustableThermostat
• Setting Range (NO): 32-140 F
  Setting Range (NO): 32-140 F

The SKTD542 twin thermostats integrates two independently switchable thermostats that use Normally-Closed contacts for Heaters and Alarms

• Dual Adjustable Thermostat
• Setting Range (NC): 32-140

The Stego EFL 012 series hygrostat is used for controlling heating and cooling equipment, filter fans or signal devices through the Relay SM 010 or a similar device. The hygrostat registers the surrounding relative humidity and can switch a signal current via an internal relay with a potential free change-over contact.

• Electronic Adjustable Hygrostat
• Humidity Setting: 40-90% RH
• Operating Voltage: 12-48 VDC
• Mounting: DIN Rail

The Stego EFR 012 series hygrostat senses the relative humidity in an enclosure and turns on a heater at the set point, helping prevent the formation of condensation in the enclosure.

• Electronic Adjustable Hygrostat
• Humidity Setting: 40-90% RH
• Operating Voltage: 120 VAC
• Mounting: DIN Rail
